MCX Female Solder RF Coaxial Connector, Bulkhead Main Specifications: General Information: Part No.: YC-617-1021 Product Series: MCX Connectors Brand: Metabee Gender: Female Orientation: Straight Number of Contacts: 1 Port Contact Termination: Solder Mount Method: Panel Mount Mount Feature: Bulkhead Fastening Type: Push-in Other Feature: None Materials and Plating: Body Material: Brass Body Plating: Nickel Plated Insulator Material: TEFLON Contact Material: Brass Contact Plating: Gold Plated Electrical Performance: Impedance: 50 Ohm Frequency: 6 GHz VSWR: ≤1.3 Max. Working Voltage: 335V rms Dielectric Withstanding Voltage: 1000 V rms Center Contact Resistance: ≤ 5.0 mΩ Max Outer Contact Resistance: ≤ 1.0 mΩ Max Insulation Resistance: ≥ 1000 MΩ (Megohms MIN.) Mechanical Performance: Coupling: Push-in Coupling nut torque: 4 in-lbs. min. Contact Retention: 15 in-lbs min. Durability: ≥ 500 Times Environmental Performance: Temperature Range: -65°C to 155°C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101 Applications of this MCX Female Solder RF Coaxial Connector: MCX connectors are miniature coaxial RF connectors widely used in various industries due to their compact size and reliable performance. Here are some common applications: Antenna Systems; Medical Devices； Test and Measurement; Satellite Communication; Telecommunications; Broadcast Equipment; Aerospace and Defense. Wi-Fi and Bluetooth Modules. Download the RF Connectors PDF Catalog: Metabee's RF Coaxial Connectors Catalog (PDF, 3.7 MB) Learn more about our RF Coaxial connectors. Factory pricing and exceptional product quality. Get a free quote now! Metabee is a professional manufacturer from China. We can provide all kinds of RF connectors.
