Product Description Brand Hikvision Country/Company of Origin China Model Name DS-D5C86RB/B Active Screen Size (Diagonal) 86 inch Glass Thickness 3.2 mm Glass Bonding Method Zero Lamination Backlight DLED Resolution 3840 × 2160 @60 Hz Brightness 400 cd/m² （Typ.） Color Depth 10 bit Response Time 6 ms Refresh Rate 60 Hz Display Area 1895.04mm ╳ 1065.96mm Working Duration 7*16H Touch Point 45 point multi-touch Touch Response Time ＜ 8 ms Operation System Android 13.0 Processor Quad-core Cortex-A76 × 4（2.4GHz）and quad-core Cortex-A55 × 4（1.8GHz） Memory 8 GB Built-in Storage 128 GB Camera Pixel Pixel 48MP for Photos & 8 MP for Video Field Angle 120°(diagonal), 110°(horizontal), 75°(vertical) Camera Resolution Ratio Up to 4K Microphone Specification Omni-directional 8-array layout Voice Distance 12 m Loudspeaker Built-in 2 ×15 W 25W loudspeaker Bluetooth Built-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.1 Video & Audio Input HDMI In （HDMI 2.0）× 3, VGA In × 1, DP In （DP 1.2）× 1, Audio In × 1 Video & audio output HDMI Out （HDMI 2.0）× 1, Audio Out × 1, SPDIF Out × 1 Control interface TOUCH-p 3.0 × 3, RS232 × 1 Network Interface LAN (1000 Mbps) × 2 WIFI AP&Station，2.4G/5G IEEE 802.11 a/b/g/n/ac 2×2 MIMO (2.4 GHz and 5 GHz) authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP Data Transmission Interface USB 3.0 × 4, USB 2.0 × 1, Type-C × 2 (Type-C supports USB 2.0, DP 1.2, and charging functions; side charging 15 W, front charging 65 W) Product dimensions 1960.5 mm × 1173.7 mm × 82.5 mm Accessory Wall mount bracket, hook, user manual, touch writing pen, packing list, 3M touch USB cable, 3M HDMI cable (2.0), 1.5m power cable (European standard), Bluetooth remote control.t Net Weight 65.13 kg NFC Support screen mirroring by Android phones Warranty Parts 3 years Warranty
